MIFARE 1K S50 Card is also called MIFARE 1K card or S50 card. Mifare 1k S50 card is based on NXP MF1 IC S50, which is connected to a coil with a few turns and then embedded into plastic to form the passive contactless smart card. The communication layer (MIFARE RF Interface) complies with part 2 and 3 of the ISO/IEC14443A standard. It is contactless transmission of data and energy and no battery is needed.
MIFARE Classic 1K is fundamentally used for storing memories, while a simple security mechanism divides the memories into segments. Therefore, it is ideal for high volume transactions in all different applications, such as transport ticketing, time attendance solutions, car parking, road-tolling, public transportation, access management, electronic toll collection, car parking, school and campus cards, employee cards, loyalty cards etc. It is mainly used in closed systems as fixed value tickets (e.g. weekly/monthly travel passes).
Parameters of Contact/Contactless chip
Chip model | Brand | Type | Frequency | Memory | Read-Write time | Data conservation | Protocal |
Mifare S50 | NXP | Contactless | 13.56Mhz | 1Kbyte | 100000 | 10 years | ISO 14443A |
Mifare S70 | NXP | Contactless | 13.56Mhz | 4Kbyte | 100000 | 10 years | ISO 14443A |
Mifare desfire 2k | NXP | Contactless | 13.56Mhz | 2Kbyte | 500000 | 10 years | ISO 14443A |
Mifare desfire 4k | NXP | Contactless | 13.56Mhz | 4Kbyte | 500000 | 10 years | ISO 14443A |
Mifare desfire 8k | NXP | Contactless | 13.56Mhz | 8Kbyte | 500000 | 10 years | ISO 14443A |
Mifare ultralight | NXP | Contactless | 13.56Mhz | 64byte | 100000 | 5 years | ISO 14443A |
Mifare PLUSS2K/X2K | NXP | Contactless | 13.56Mhz | 2byte | 200000 | 10 years | ISO 14443A |
M1 PLUSS2K/4K | NXP | Contactless | 13.56Mhz | 4byte | 200000 | 10 years | ISO 14443A |
I-CODE SLI | NXP | Contactless | 13.56Mhz | 1024bits | 100000 | 40 years | ISO15693 |
HITAG1 | NXP | Contactless | 125KHZ | 2048bits | 100000 | 10 years | ISO11784/785 |
HITAG2 | NXP | Contactless | 125KHZ | 256bits | 100000 | 10 years | ISO11784/785 |
HITAG3 | NXP | Contactless | 125KHZ | 256/2048bits | 100000 | 10 years | ISO11784/785 |
FM11RF08 | FUDAN | Contactless | 13.56Mhz | 1Kbyte | 100000 | 10 years | ISO14443A |
FM11RF32 | FUDAN | Contactless | 13.56Mhz | 4Kbyte | 100000 | 10 years | ISO14443A |
FM1208 series | FUDAN | Contactless | 13.56Mhz | 8Kbyte | 100000 | 10 years | ISO14443A |
FM1204 | FUDAN | Contactless | 13.56Mhz | 4Kbyte | 100000 | 10 years | ISO14443A |
Legic256 | Legic | Contactless | 13.56Mhz | 256byte | 100000 | 10 years | |
Ti2048 | TI | Contactless | 13.56Mhz | 256byte | 100000 | 10 years | ISO15693 |
ID4001/4100 | RUIXIN | Contactless | 125KHZ | – | 100000 | 10 years | – |
EM4200/4305 | EM | Contactless | 125KHZ | – | 100000 | 10 years | – |
T5577 | ATMEL | Contactless | 125KHZ | 330bits | 100000 | 10 years | ISO1178/785 |
U-CODE HSL | HSL | Contactless | 915KHZ | 2048bits | 100000 | 10 years | ISO18000-6B |
Alien9662(H3) | ATMEL | Contactless | 915KHZ | 96bit EPC/512Bit usermemory | 100000 | 10 years | ISO18000-6C |
Fm1216 series | FUDAN | Contactless | 13.56Mhz | 16Kbyte | 100000 | 10 years | ISO14443A |
SLE4442/5542 | SIEMENS | Contact | – | 256byte | 100000 | 10 years | ISO7816 |
SLE4428/5528 | SIEMENS | Contact | – | 1byte | 100000 | 10 years | ISO7816 |
45DB041 | ATMEL | Contact | – | 528Kbyte | 100000 | 10 years | ISO7816 |
AT88SC102 | ATMEL | Contact | – | 1024bits | 100000 | 10 years | ISO7816 |
AT88SC1604 | ATMEL | Contact | – | 5704bits | 100000 | 10 years | ISO7816 |
AT88SC153 | ATMEL | Contact | – | 2048bits | 100000 | 10 years | ISO7816 |
24 series | Contact | – | 1k-64kbits | 100000 | 10 years | ISO7816 |
